Product Number: 130B0295
Frequency converterFC-302P75KT5E20H2BGXXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-302(P75K) 75 KW / 100 HP
Three phase380 - 500 VAC
(E20) IP20 / Chassis
RFI FilterBrake chopper
Graphical Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: C4
Other options according to Model code
Frequency converterFC-202P315T4E5MN2TGC3XXSXXXXAXBXCXXXXDXVLT®
AQUA Drive FC-202(P315) 315 KW / 450 HP
Three phase380 - 480 VACIP54/Type 12+main shieldLHD - AAF006 filter + A2
RFISafe Stop
Graphical Loc. Cont. PanelCoated PCBMains Disconnect + Fuse
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: E9
Other options according to Model code
