Product Number: 134B1728
Frequency converterFC-302P1K5T5Z55H1XGXXXXSXXXXA0BXCXXXXD0VLT®
AutomationDrive FC-302(P1K5) 1.5 KW / 2.0 HP
Three phase380 - 500 VACIP55 / Type 12 A4
Frame(H1)
RFI Class A1/B (C1)
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.PROFIBUS DP MCA 101, No B OptionNo C1 option, MCB-107 24V DC backupFrame: A4
Other options according to Model code
Frequency converterFC-302P37KT5E55H2XGCXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-302(P37K) 37 KW / 50 HP
Three phase380 - 500 VACIP55 / Type 12
RFI Filter
No brake chopper
Graphical Loc. Cont. PanelCoated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: C1
Other options according to Model code
Type: BWD500210
for VLT types: FCD322 / 2815 (380-480V) / 5004 (380-500V) / FC300 PK55(200-240V) / FC300P2K2 (380-480 / 500V)
(hereinafter general technical data on the braking resistor,
Duty cycle / braking power depends on the frequency converter
Nominal power: 200W
Resistance value: 210Ohm
Braking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000W
Degree of protection: IP65
Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg
