Product Number: 134X3054L
Frequency converterFC-302P15KT5E55H2XGXXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-302(P15K) 15 KW / 20 HP
Three phase380 - 500 VACIP55 / Type 12
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: B1
Other options according to Model code
Frequency converterFC-302P37KT5E20H2XGCXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-302(P37K) 37 KW / 50 HP
Three phase380 - 500 VAC
(E20) IP20 / Chassis
RFI Filter
No brake chopper
Graphical Loc. Cont. PanelCoated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: C3
Other options according to Model code
Frequency converterFC-302P160T5E21H2XGX7XXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-302(P160) 160 KW / 250 HP
Three phase380 - 500 VACIP21 / Type 1
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCBFuse
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: D2
Other options according to Model code
