Product Number: 195N0073
Frequency converterFC-302N160T5E21N2XGCXXXSXXXXA0BXCXXXXDXVLT®
AutomationDrive FC-302(N160) 160 KW / 250 HP
Three phase380 - 500 VACIP21 / Type 1LHD - AAF006 filter + A2
RFI
No brake chopper
Graphical Loc. Cont. PanelCoated PCB
No Mains Option
Latest release std. SW.PROFIBUS DP MCA 101, No B OptionNo C1 option, No D option
Frame: D2n
Other options according to Model code
Frequency converterFC-302P90KT7E21H2BGC7XXSXXXXA0BXCXXXXDXVLT®
AutomationDrive FC-302(P90K) 90 KW / 125 HP
Three phase525 - 690 VAC *IP21 / Type 1
RFI FilterBrake chopper
Graphical Loc. Cont. PanelCoated PCBFuse
Latest release std. SW.PROFIBUS DP MCA 101, No B OptionNo C1 option, No D option
Frame: D1
Other options according to Model code
Frequency converterFC-302P1K5T5E66H1XGXXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-302(P1K5) 1.5 KW / 2.0 HP
Three phase380 - 500 VAC(E66) IP66 / NEMA 4X(H1)
RFI Class A1/B (C1)
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: A5
Other options according to Model code
Frequency ConverterFC-051P11KT4E20H3BXCXXXSXXXVLT®
Micro Drive FC-51(P11K) 11 KW / 15 HP
Three phase380 - 480 VAC
(E20) IP20 / Chassis(H3)
RFI Class A1/B (C1)Brake chopper
No Loc. Cont. PanelCoated PCB
No Mains OptionM4-FRAME
Other options according to Model code
