IGBT Kit VLT5152

MCD50053BT5G1X20CV1

175G5503This product has been discontinued.

MCD50053BT5G1X20CV1

VLT® Soft Starter MCD 500200-525 VAC, 53A, IP20,

Control Voltage: 24 VAC/VDC

Model code:MCD50053BT5G1X20CV1

VLT® Soft Starter MCD 500 is a total motor starting solution.Current transformers measure motor current and provide feedback for controlled motor ramp profiles. AAC, the Adaptive Acceleration Control automatically employs the best starting and stopping profile for the application

Type: BWD500210

for VLT types: FCD322 / 2815 (380-480V) / 5004 (380-500V) / FC300 PK55(200-240V) / FC300P2K2 (380-480 / 500V)

(hereinafter general technical data on the braking resistor,

Duty cycle / braking power depends on the frequency converter

Nominal power: 200W

Resistance value: 210Ohm

Braking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000W

Degree of protection: IP65

Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg

Frequency ConverterFC-102P2K2T4E20H2XGXXXXSXXXXAXBXCXXXXDXVLT®

HVAC Drive FC-102(P2K2) 2.2 KW / 3.0 HP

Three phase380 - 480 VAC

(E20) IP20 / Chassis

RFI Filter

No brake chopper

Graphical Loc. Cont. Panel

Not coated PCB

No Mains Option

Latest release std. SW.

No A Option, No B OptionNo C1 option, No D option

Frame: A2

Other options according to Model Code
