Danfoss Inverter FC302 1.1kW 380-500VAC/3PH IP20

Type: BWD500210

for VLT types: FCD322 / 2815 (380-480V) / 5004 (380-500V) / FC300 PK55(200-240V) / FC300P2K2 (380-480 / 500V)

(hereinafter general technical data on the braking resistor,

Duty cycle / braking power depends on the frequency converter

Nominal power: 200W

Resistance value: 210Ohm

Braking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000W

Degree of protection: IP65

Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg

Frequency converterFC-302P90KT5E00H2XGXXXXSXXXXAXBXCXXXXDXVLT®

AutomationDrive FC-302(P90K) 90 KW / 125 HP

Three phase380 - 500 VAC(E00) IP00 / Chassis

RFI Filter

No brake chopper

Graphical Loc. Cont. Panel

Not coated PCB

No Mains Option

Latest release std. SW.

No A Option, No B OptionNo C1 option, No D option

Frame: D3

Other options according to Model code

Frequency converterFC-301P5K5T4E20H1BGCXXXSXXXXAXBXCXXXXDXVLT®

AutomationDrive FC-301(P5K5) 5.5 KW / 7.5 HP

Three phase380 - 480 VAC

(E20) IP20 / Chassis(H1)

RFI Class A1/B (C1)Brake chopper

Graphical Loc. Cont. PanelCoated PCB

No Mains Option

Latest release std. SW.

No A Option, No B OptionNo C1 option, No D option

Frame: A3

Other options according to Model code
