Product Number: 175U0987
Type: BWD500210
for VLT types: FCD322 / 2815 (380-480V) / 5004 (380-500V) / FC300 PK55(200-240V) / FC300P2K2 (380-480 / 500V)
(hereinafter general technical data on the braking resistor,
Duty cycle / braking power depends on the frequency converter
Nominal power: 200W
Resistance value: 210Ohm
Braking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000W
Degree of protection: IP65
Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg
Type: BWD500210
for VLT types: FCD322 / 2815 (380-480V) / 5004 (380-500V) / FC300 PK55(200-240V) / FC300P2K2 (380-480 / 500V)
(hereinafter general technical data on the braking resistor,
Duty cycle / braking power depends on the frequency converter
Nominal power: 200W
Resistance value: 210Ohm
Braking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000W
Degree of protection: IP65
Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg
Frequency converterFC-280P15KT4E20H2BXCXXXSXXXXA0VLT®
Midi Drive FC-28015 kW / 20 HP
Three phase 380-480 VACIP20 / ChassisEMC Cat C3 (200/400V)Brake chopperNo displayCoated PCB,
Latest releaseIntegrated Profibus DP
Frame: K4
Other options according to Model code
Frequency ConverterFC-102P110T4E00H2XGXXXXSXXXXAXBXCXXXXDXVLT®
HVAC Drive FC-102(P110) 110 KW / 150 HP
Three phase380 - 480 VAC(E00) IP00 / Chassis
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: D3
Other options according to Model Code
