Current Scalingf for P132KW FC102,202 & P110KW FC302 All Enclosure

Frequency ConverterFC-051P2K2S2E20H3BXCXXXSXXXVLT®

Micro Drive FC-51(P2K2) 2.2 KW / 3.0 HP

Single phase200 - 240 VAC

(E20) IP20 / Chassis(H3)

RFI Class A1/B (C1)Brake chopper

No Loc. Cont. PanelCoated PCB

No Mains OptionM3-FRAME

Other options according to Model code

Frequency converterFC-302P22KT5E55H2XGCXXXSXXXXAXBXCXXXXDXVLT®

AutomationDrive FC-302(P22K) 22 KW / 30 HP

Three phase380 - 500 VACIP55 / Type 12

RFI Filter

No brake chopper

Graphical Loc. Cont. PanelCoated PCB

No Mains Option

Latest release std. SW.

No A Option, No B OptionNo C1 option, No D option

Frame: B2

Other options according to Model code

Frequency ConverterFC-051P18KT4E20H3BXCXXXSXXXVLT®

Micro Drive FC-51(P18K) 18.5 KW / 25 HP

Three phase380 - 480 VAC

(E20) IP20 / Chassis(H3)

RFI Class A1/B (C1)Brake chopper

No Loc. Cont. PanelCoated PCB

No Mains OptionM5-FRAME

Other options according to Model code
