Product Number: 178B8595
MCD60069BT5S1X20CV2
136G7348
MCD60069BT5S1X20CV2VLT® Soft Starter MCD 600With Int. Bypass Contactor69 A, Three phase 200-525 V ACFrame size 1, IP20Control Voltage: 110~120 VAC or 220~240 VACOther options according to Model codeModel code:
MCD60069BT5S1X20CV2
VLT® Soft Starter MCD 600 is a total motor starting solution.Current transformers measure motor current and provide feedback forcontrolled motor ramp profiles.Adaptive Acceleration
Frequency converterFC-302P2K2T5E20H1XXXXXXSXXXXA0BXCXXXXDXVLT®
AutomationDrive FC-302(P2K2) 2.2 KW / 3.0 HP
Three phase380 - 500 VAC
(E20) IP20 / Chassis(H1)
RFI Class A1/B (C1)
No brake chopper
No Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.PROFIBUS DP MCA 101, No B OptionNo C1 option, No D option
Frame: A2
Other options according to Model code
