Brake Resistor Flatpack 310 Ohm/200 watt untuk Inverter 1.5kw/380Vac, 14%
Type: BWD500310for VLT types: FCD315 / 2815 (380-480V) / 5003 (380-500V) / FC300 PK37(200-240V) / FC300P1K5 (380-480 / 500V)(hereinafter general technical data on the braking resistor,Duty cycle / braking power depending on the frequency converterNominal power: 200WResistance value: 310OhmBraking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000WDegree of protection: IP65Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg
