IGBT Dual Module for N110KW FC102,202 & N90KW FC302 All Enclosure
Product Number: 176F3362
176F3362
4 other products in the same category:
Danfoss Inverter FC302 110KW 380VAC/3PH IP20
Frequency converterFC-302N110T5E20H2BGCXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-302(N110) 110 KW / 150 HP
Three phase380 - 500 VAC
(E20) IP20 / Chassis
RFI FilterBrake chopper
Graphical Loc. Cont. PanelCoated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: D3H
Other options according to Model code
Danfoss Softstarter MCD500 15Kw/200-525VAC/37A/IP20
MCD50037BT5G1X20CV1
175G5501This product has been discontinued.
MCD50037BT5G1X20CV1
VLT® Soft Starter MCD 500200-525 VAC, 37A, IP20,
Control Voltage: 24 VAC/VDC
Model code:MCD50037BT5G1X20CV1
VLT® Soft Starter MCD 500 is a total motor starting solution.Current transformers measure motor current and provide feedback for controlled motor ramp profiles. AAC, the Adaptive Acceleration Control automatically employs the best starting and stopping profile for the application
