Plastik Busbar from IGBT to U V W 37 - 55KW FC102,202 & 30 - 45KW FC300 IP21,54,55,66
Product Number: 130B3912
130B3912
4 other products in the same category:
Danfoss Inverter FC301 1.1kW 380VAC/3PH IP20
Frequency converterFC-301P1K1T4E20H2XGXXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-301(P1K1) 1.1 KW / 1.5 HP
Three phase380 - 480 VAC
(E20) IP20 / Chassis
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D option
Frame: A2
Other options according to Model code
Viewed products
Brake Resistor Flatpack 310 Ohm/200 watt untuk Inverter 1.5kw/380Vac, 14%
Type: BWD500310for VLT types: FCD315 / 2815 (380-480V) / 5003 (380-500V) / FC300 PK37(200-240V) / FC300P1K5 (380-480 / 500V)(hereinafter general technical data on the braking resistor,Duty cycle / braking power depending on the frequency converterNominal power: 200WResistance value: 310OhmBraking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000WDegree of protection: IP65Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg
Brake Resistor Flatpack 210 Ohm/200 watt untuk Inverter 2.2kw/380Vac,10%
Type: BWD500210
for VLT types: FCD322 / 2815 (380-480V) / 5004 (380-500V) / FC300 PK55(200-240V) / FC300P2K2 (380-480 / 500V)
(hereinafter general technical data on the braking resistor,
Duty cycle / braking power depends on the frequency converter
Nominal power: 200W
Resistance value: 210Ohm
Braking power:40% ED / cycle time 120s 400W30% ED / cycle time 120s 500W20% ED / cycle time 120s 700W10% ED / cycle time 120s 1200W5% ED / cycle time 120s 2000W2% ED / cycle time 120s 4000W
Degree of protection: IP65
Dimensions HxWxD: 216 x 80 x 15mmWeight: 0.6kg
Danfoss Inverter FC301 0.55kW 380VAC/3PH IP20 (Z20 Frame A1 STANDARD
Frequency converterFC-301PK55T4Z20H2XGXXXXSXXXXAXBXCXXXXDXVLT®
AutomationDrive FC-3010.55 KW / 0.75 HP
Three phase380 - 480 VACIP20 / Chassis A1
Frame
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB
No Mains Option
Latest release std. SW.
No A Option, No B OptionNo C1 option, No D optionFrame: A1
Other options according to Model code
